INTRODUCTION
Single Compression Gland as per IS13942 or as per IS-1394 the compression is effected only at one place (i.e.) at the cable armour only. There is scope for moisture and corrosive vapour to enter the gland and thus into the cable. Generally single compression glands are used for light armored cables
CONSTRUCTION
Technical Data
| Material |
Brass (IS -391) Standard (Alu./ S.S./M.S./aslo available) |
| Finish |
Bright Nickel Plated (Tin/Cadmium/Chrome also available) |
| Entry Threads |
Metric Standard (BSC/PG/NPT/BSP also available) |
| Sealing Ring |
Natural |
| Ref. Standard |
IS 12943 - 1990 |
| Ingress Protection |
IP 60 as per IS 13947 |
| Application |
Generally for indoor use for Armoured & Unarmoured Cables |
Parts of Glands
- Check Nut
- Main Gland Body
- Metal Washer (3. Nos)
- Outer sheath Rubber
- Gland Cover
As all the metal parts are made of brass, as per the approved drawing.
Accessories
Single compression glands are used in regular climatic conditions, which are weather proof & dust proof (IP60). With the protection of PVC Hood it can be used in different areas.
APPLICATION
Single compression glands are used in regular climatic conditions, which are weather proof & dust proof (IP60). With the protection of PVC Hood it can be used in different areas.
FAQ
PRICING
Contact us for more information on Single Compression Heavy Duty (Sibg Type) Cable Glands or to discuss your requirements. Enquiries are solicited for India, UAE and Africa on following Email id web@aakashpower.com
